Starter for Forklifts - A starter motors today is typically a permanent-magnet composition or a series-parallel wound direct current electrical motor with a starter solenoid installed on it. As soon as current from the starting battery is applied to the solenoid, mainly via a key-operated switch, the solenoid engages a lever which pushes out the drive pinion that is located on the driveshaft and meshes the pinion using the starter ring gear which is seen on the flywheel of the engine.
The solenoid closes the high-current contacts for the starter motor, which begins to turn. Once the engine starts, the key operated switch is opened and a spring within the solenoid assembly pulls the pinion gear away from the ring gear. This particular action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by means of an overrunning clutch. This permits the pinion to transmit drive in only a single direction. Drive is transmitted in this manner via the pinion to the flywheel ring gear. The pinion continuous to be engaged, for instance since the operator did not release the key as soon as the engine starts or if the solenoid remains engaged for the reason that there is a short. This actually causes the pinion to spin separately of its driveshaft.
The actions mentioned above would stop the engine from driving the starter. This significant step prevents the starter from spinning so fast that it can fly apart. Unless modifications were done, the sprag clutch arrangement would stop utilizing the starter as a generator if it was used in the hybrid scheme mentioned earlier. Usually a standard starter motor is intended for intermittent use that would prevent it being utilized as a generator.
The electrical components are made to be able to operate for around 30 seconds so as to stop overheating. Overheating is caused by a slow dissipation of heat is due to ohmic losses. The electrical parts are meant to save cost and weight. This is actually the reason most owner's instruction manuals for automobiles suggest the driver to pause for at least 10 seconds right after each 10 or 15 seconds of cranking the engine, whenever trying to start an engine that does not turn over right away.
The overrunning-clutch pinion was introduced onto the marked during the early 1960's. Prior to the 1960's, a Bendix drive was used. This particular drive system functions on a helically cut driveshaft which consists of a starter drive pinion placed on it. As soon as the starter motor starts spinning, the inertia of the drive pinion assembly allows it to ride forward on the helix, hence engaging with the ring gear. When the engine starts, the backdrive caused from the ring gear enables the pinion to go beyond the rotating speed of the starter. At this moment, the drive pinion is forced back down the helical shaft and thus out of mesh with the ring gear.
In the 1930s, an intermediate development between the Bendix drive was made. The overrunning-clutch design that was developed and introduced during the 1960s was the Bendix Folo-Thru drive. The Folo-Thru drive consists of a latching mechanism along with a set of flyweights inside the body of the drive unit. This was a lot better since the standard Bendix drive utilized in order to disengage from the ring as soon as the engine fired, though it did not stay running.
Once the starter motor is engaged and starts turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. Once the drive unit is spun at a speed higher than what is achieved by the starter motor itself, for instance it is backdriven by the running engine, and after that the flyweights pull outward in a radial manner. This releases the latch and allows the overdriven drive unit to become spun out of engagement, thus unwanted starter disengagement could be prevented previous to a successful engine start.
